GATE 2016 · CS1 - Forenoon
Theory of ComputationPush Down Automata: CFL & DCFLmediumMCQ2 marks
Consider the transition diagram of a PDA with Σ = {a, b} and stack alphabet Γ = {X, Z}. Z is the initial stack symbol. Transitions: - On 'a' from state 0: pushes X onto stack - State 0 is accepting. - On 'b' from state 0 with top X: pops X and transitions to state 1 - In state 1, on 'b' with top X: pops X - From state 1, on ε with top Z: transitions to state 2 (accepting). Which statement is TRUE?
